Φ4X13.7mm 635nm 0.3mW 0.5mW 1mW 5mW 10mW 3V-5V Dot Red Light Laser Module Laser

Be the first to review this product

was $25.37 Special Price $20.86

Based in Wuhan, Central China Hubei Province, Lilly Electronics is engaged in fabrication, sales and R&D of consumer electronics maninly in the industry of Laser, IC and LED! You are welcome to visit us for culture exchange and mutrual business development and progress.

Availability:

In stock

SKU

635MD-0.3-10mW-0414-CAB-BLK-Cu

Details

Title：	Φ4X13.7mm 635nm 0.3mW 0.5mW 1mW 5mW 10mW 3V-5V Dot Red Light Laser Module Laser
Circuit Mode:	APC circuit	Wavelength:	635nm
Output Power:	< 0.3mW，< 0.5mW，< 1mW，< 5mW，< 10mW	Working Voltage:	3~5VDC
Working Current:	<25mA(0.3mW/0.5mW)，<30mA(1mW)，<50mA(5mW)，<70mA(10mW)	Surface treatment/color:	brass shell (natural color)/black shell, surface insulation, oxidation mist black treatment
Shell Material:	Copper/Aviation Aluminum (Full Metal Shell)	Spot shape and size:	dotted light, elliptical light
Working Temperature:	-10 ° C ~ 50 ° C	Storage Temperature:	-20 ° C ~ 60 ° C
Service Life:	>8000H	Laser Rating:	Class I(0.3mW)，ClassII(0.5mW/1mW)，Class IIIA(5mW)，Class IIIB(10mW/)
Surface treatment/color:	brass shell (natural color)/black shell, surface insulation, oxidation mist black treatment	Range:	<200 meters (indoor environment, laser may be affected by ambient light interference, distance may vary)
Focusing method:	adjustable focus	Size:	φ4X13.7mm
Package:	1*635nm Laser Module
