Model No. |
LSR532NL |
|
Wavelength |
532nm |
|
Spatial Mode |
TEM00 |
|
Output Power |
100mw |
|
Residual IR (946, 1064&808nm) |
<0.01% |
|
Operation Mode |
CW or Modulation |
|
Modulation |
0~30khz Analog or TTL (Optional, please note to us if you need Analog or TTL, we will send Analog as default ) |
|
Beam Spot Shape |
Circular, aspect ratio<1.1:1 |
|
Pointing Stability |
<0.05 mrad |
|
Beam Diameter(1/e2) |
<2.5 mm |
|
Beam Divergence(full angle) |
<1.5 mrad |
|
Power Stability |
<±5% per 4 hrs |
|
Temperature Stabilizing |
TEC |
|
Warm Up Time |
<1 minute |
|
MTTF |
10,000 hrs |
|
Laser head dimensions |
100(L)x40(W)x50(H)mm3 (fan adds height) |
|
Power Supply (Optional, note to us which type you need, choose B or C type for addtional cost as below. We will ship Power supply A type as default) |
A. OEM type LSR-PS-I: 100(L)x58(W)x32(H)mm3 AC/DC PSU: 85~265V 50/60Hz input |
|
B. Lab type LSR-PS-IIS: 104(W)x128(D)x89(H)mm3 85~265V 50/60Hz input |
|
|
C. Lab Adjustable type LSR-PS-IIS: 179(W)x148(D)x56(H)mm3 85~265V 50/60Hz input |
|
|
Modulation |
0~30khz Analog or TTL |
| Price | $376.50 |
|---|---|
| Power | 100mw |
| Price View | Price Range |
