Φ4X8mm 980nm 5mW 10mW 20mW 30mW 50mW 3-5V Infrared Invisible Light Dot Laser Module

was $42.00 Special Price $35.00
Size: φ4X8mm
Material: Copper/Aviation Aluminum (Full Metal Shell)
Surface treatment/color: brass shell (natural color)/black shell, surface insulation, oxidation mist black treatment
Wavelength: 980nm ± 10nm
Exit pupil power:< 5mW,< 10mW,< 20mW,< 30mW,< 50mW
Range:<600 meters (indoor environment, laser may be affected by ambient light interference, distance may vary) Spot shape and size: dotted light, elliptical light
Focusing method: adjustable focus
Circuit control: APC circuit
Working voltage: 2.8~5.2VDC
Working current:< 35mA(0.5mW),<45mA(10mW),<60mA(20mW),<75mA(30mW),<85mA(50mW)
Availability:
In stock
SKU
980MD-5-50mW-0408-3-5V-CAB-BLK-CU
  • Buy 5 for $33.20 each and save 5%
  • Buy 20 for $28.00 each and save 20%
  • Buy 50 for $21.00 each and save 40%
Specifications:
Size: φ4X8mm
Material: Copper/Aviation Aluminum (Full Metal Shell)
Surface treatment/color: brass shell (natural color)/black shell, surface insulation, oxidation mist black treatment
Wavelength: 980nm ± 10nm
Exit pupil power:< 5mW,< 10mW,< 20mW,< 30mW,< 50mW
Range:<600 meters (indoor environment, laser may be affected by ambient light interference, distance may vary) Spot shape and size: dotted light, elliptical light
Focusing method: adjustable focus
Circuit control: APC circuit
Working voltage: 2.8~5.2VDC
Working current:< 35mA(0.5mW),<45mA(10mW),<60mA(20mW),<75mA(30mW),<85mA(50mW)
Working temperature:- 10℃~+50℃
Storage temperature:- 20℃~+70C
Service life: Continuous output>10000 hours
Tail wire: 28 # red and black electronic wire, approximately 15cm long
Security level: Class IIIA(5mW),Class IIIB(10mW/-50mW)

Packaging:
1x Φ4X8mm 980nm 5mW 10mW 20mW 30mW 50mW 3-5V Infrared Invisible Light Dot Laser Module
