785nm 150mW Laser Coupler Splitter Fiber Infrared Laser Module w/ Driver Board

Be the first to review this product
was $273.00 Special Price $227.00
Output wavelength:785±10nm
Output power:<100mW
Size:6*16MM
Fiber Material: Quartz
Fiber core diameter: 200 microns
Fiber length: 1 meter
Connector type: FC connector (customizable)
Spot shape: astigmatism
Coupling lens material: optical glass
Bare tube starting voltage:DC2.2V
Circuit control mode: ACC constant current control board
Plus driver board voltage: DC3-5V
Bare tube maximum working current:
Wire: UL1571 28#150MM red and black electronic wire
Working temperature:-10 ° C ~ +60 ° C
Storage temperature:-20 ° C ~ +85° C
Availability:
In stock
SKU
SHHO-GQ7801503D6-CU-DR
Add to Wish List Add to Compare
Specifications: Output wavelength:785±10nm
Output power:<100mW
Size:6*16MM
Fiber Material: Quartz
Fiber core diameter: 200 microns
Fiber length: 1 meter
Connector type: FC connector (customizable)
Spot shape: astigmatism
Coupling lens material: optical glass
Bare tube starting voltage:DC2.2V
Circuit control mode: ACC constant current control board
Plus driver board voltage: DC3-5V
Bare tube maximum working current:
Wire: UL1571 28#150MM red and black electronic wire
Working temperature:-10 ° C ~ +60 ° C
Storage temperature:-20 ° C ~ +85° C

Package:
1 x 785nm 150mW Laser Coupler Splitter Fiber Infrared Laser Module w/ Driver Board
