Specification:
Including 2.4" TFT LCD Touchscreen
CPU: STM32F103VET6, TQFP 100 pins
FLASH: 512K BYTES, SRAM:64K BYTES
1*JTAG debug interface
1*power LED indicattor (Green), 1 status LED (Blue)
1*RS232 port, Need crossover cable to talk to PC
Support 3 pin ISP
1*USB2.0 SLAVE port
1*Micro SD(TF) slot, uses SDIO
1*2.4 inch TFT (240X320 (touch screen) ), use FSMC 16 bits interface to control
1*SPI interfaced AT45DB161D(2M BYTES) serial FLASH
1*functional botton
1*RTC battery socket
All unused GPIO pins are connected to external headers.
Feature:
Operation Voltage :
Board is designed to use 5V power supply only and powered by usb interface.
Package:
1 x ARM Cortex-M3 MINI STM32 Dev Board +2.4" TFT LCD Touchscreen
