Model No.:LSR808NL Wavelength:808±10nm Spatial Mode:Multimode Output Power:2000 mW (1w-5w can be customized) Operation Mode:CW or Modulation Modulation:Analog or TTL 0~30Khz (Note to us if you nee Analog or TTL, optional) Polarization:TM Pointing Stability:<0.05 mrad Beam Diameter(1/e2):<4mm Beam Divergence:<3mrad Power Stability:<±3% per 2 hrs Temperature Stabilizing:TEC Warm Up Time:<2 minutes
Please note that this module will be customized for 7-10 days.So we can't ship it out until 7 days later.Kindly please understand us!
Specification:
Model No.:LSR808NL
Wavelength:808±10nm
Spatial Mode:Multi-mode
Output Power: 100mw, 1w-5w can be customized
Operation Mode:CW or Modulation
Modulation:Analog or TTL 0~30Khz (Note to us if you nee Analog or TTL, optional)
Polarization:TM
Pointing Stability:<0.05 mrad
Beam Diameter(1/e2):<4mm
Beam Divergence:<3mrad
Power Stability:<±3% per 2 hrs
Temperature Stabilizing:TEC
Warm Up Time:<2 minutes
MTTF: 5,000 hrs
Dimensions:100(L)x40(W)x50(H) mm
Power Supply (Optional)
A. OEM type
LSR-PS-I: 100(L)x58(W)x32(H)mm3
AC/DC PSU: 85~265V 50/60Hz input
B. Lab type
LSR-PS-IIS: 104(W)x128(D)x89(H)mm3
85~265V 50/60Hz input
C. Lab Adjustable type
LSR-PS-IIS: 179(W)x148(D)x56(H)mm3
85~265V 50/60Hz input
Application:
Laser show
Display
Laser Alignment
Scanning Biochemistry
Material Inspection Lidar
Feature:
Miniature size
Collimated straight beam
Adjustible focuse
Easy use & maintenance free
Longlife operation
High efficiency
High reliability
