Product Parameters:
Interface Features: EIA/TIA Compatible RS-232C, RS-485 Standard
Electrical Interface: RS-232 End DB9 Hole Connector, RS-485 End DB9 Pin Connector
Working Mode: Asynchronous Half-Duplex Differential Transmission
Transmission Introduction: Twisted Pair Or Shielded Line
Transmission Rate: 300bps-115.2Kbps
Transmission Distance: 5 M On The RS-232 End And 1200 M OnThe RS-485
Dimensions: 63*33*17mm
Storage Temperature: -25 ° C ~ 70 ° C
Relative Humidity: 5%-95%
Certification: CE, FCC
Features:
1. Two-way conversion, wide range of use
2. The main control chip, the data is not lost
3. Long distance transmission, up to 1200 meters
4. No power supply, 232 charge pump drive
5. Fast conversion, zero delay transceiver
6. Environmentally friendly materials, good durability and good quality
Application:
Widely used in automation control systems, access control systems, parking systems, autonomous banking systems, bus toll systems, attendance systems, highway toll station systems, etc.
